SPORE v2 — the technical reference

One document: the wire format (normative, frozen), the application layer built on it (conventions, no relay support required), and where the core runs (the portable kernel and what a host owes it).

Worked bytes for every rule here: Rebuild guide. Per-medium parameters (≈70 media): Bridges. Adversaries in depth, with residual risk stated per row: Threat model.

Four parts, and the headings below are them — the previous text promised "Parts 1 and 2" against a document that had no Part 1 and a Page 2, so the claim could not be checked against anything.

Parts I and II are normative: implement them and you interoperate. Part III is what endpoints say to each other, and a relay MUST NOT require any of it. Part IV is how the core is embedded, and changes nothing on the wire.

0. The whole protocol in one breath

A SPORE message is a signed postcard: to, from, when it was written, payload, signature. Its SHA-256 fingerprint is its identity. Every node keeps postcards it hasn't seen, hands copies to anyone it meets who wants them, and drops duplicates and expired mail. That alone is a working planetary network. Of the four hard features — forward secrecy, fragmentation, congestion control, anonymity — only congestion control touches the router. Forward secrecy and anonymity live inside payloads; fragmentation lives below the router, in the bridge, where a hop that cannot carry a frame splits it and the far end puts it back.

flowchart TB
  subgraph T0["T0 carry — about 60 lines. a working network on its own"]
    A["parse"] --> B["dedup"] --> C["store"] --> D["deliver"] --> E["damped flood"]
  end
  subgraph T1["T1 sync — plus about 80"]
    F["ANNOUNCE"] --> G["INV / WANT"]
  end
  subgraph T2["T2 route — plus about 100"]
    I["paths"] --> J["directed unicast"] --> K["custody"]
  end
  T0 --> T1 --> T2
  LF["link fragmentation sits *under* all three: a property of a link, not of the router"]
  LF -.-> T0

Tiers (all interoperate): T0 carry ≈60 lines: parse, dedup, store, deliver, damped flood · T1 sync +≈80: ANNOUNCE/INV/WANT · T2 route +≈100: paths, directed unicast, custody. Endpoint extras (ratchet, mix) never change relays. Link fragmentation sits under all three: it is a property of a link, not of the router, and a node that never meets a narrow link never runs it.

Threat model, stated once: every link is hostile — logged, spoofed, jammed, MITM'd. Links are trusted with nothing; authenticity and secrecy live only in the envelope. Attackers can drop or delay; redundancy and flood-fallback heal both.

Part I — Wire (frozen at ver 0x02)

Three kinds of rule, and which is which. The audit that prompted this table was right that the distinction was implied rather than stated, and that a reader could not tell whether an unpinned behaviour was extensible or merely undocumented.

The third row is the one that keeps growing, and deliberately: every time a decision moves from the wire into a node's own hands — how long to carry something, how much repair to send, how big a file to push — the protocol gets smaller and the implementations get more room. A reader who finds a number in this document and cannot tell which row it is in should treat that as a documentation bug.

What "frozen" covers, exactly. reference/vectors.json is the compatibility surface, and CI refuses to change it. It pins the seed → public key → address derivation, topic derivation, the envelope's encoding, the ID that is the hash of that encoding with hops zeroed, the signature over it, armor, and that a tampered wire is detected. That is §1 and §2.

It does not pin §3's fragment payload, the INV/WANT payload shapes, the file layer's tags, or link framing. Those are wire in the sense that bytes cross a link, and they have changed: §3's index and count went from one byte to two, and a sealed root now names its header rather than carrying it. Both were deliberate and neither needed a major-version label, because the guard correctly did not consider them frozen.

They are pinned, though — one tier down. reference/versioned_vectors.json covers link framing (including KISS), the INV/WANT payload shapes with their two traps, the three manifest encodings, and the forwarding decisions. CI regenerates it and refuses a stale diff, exactly as it does for the frozen file; what differs is the promise. A minor release may change it. A minor release may not change vectors.json.

The distinction is the point. Pinning both in one file would say the two have the same stability, and it would make every legitimate change to link framing carry the allow-frozen-change label — which is how a guard stops meaning anything. Build against both; know which is which.

Why the second file exists at all. An envelope is where interop starts, not where it finishes. A node that reproduces every byte in vectors.json and cannot parse an INV, cannot reassemble a frame its link had to split, and cannot read a manifest is wire-compatible and unable to talk to anyone.

Saying so matters more than it looks. A third-party T0 built against "Part I is frozen" would have assumed the fragment header was stable. It was not: §3's end-to-end form has since been removed entirely, replaced by Part II's link fragmentation plus a stated envelope ceiling. Build against the vectors; treat the rest of Part I as current, not permanent.

1. Identity & addressing

Identity = one Ed25519 keypair. Address = first 8 B of SHA-256(pubkey). Topic = first 8 B of SHA-256(UTF-8 string). No global namespace; exchange keys by QR/paper/voice. Petnames are local.

2. Envelope (the only object; big-endian; fixed part = 16 B)

packet-beta
0-7: "ver = 0x02"
8-15: "type"
16-23: "flags"
24-31: "hops"
32-63: "created_at (u32, unix seconds)"
64-127: "dest (8 B) — address | topic | 0x00×8 = public"
128-383: "src — present only if SIGNED: 32-B pubkey, or 8 B if SRC8"
384-399: "plen (u16)"
400-527: "payload (plen bytes)"
528-1039: "sig — Ed25519 over everything above, hops zeroed (SIGNED only)"

The fixed part is the first 16 bytes. Everything after dest is conditional:

off len field
0   1   ver    = 0x02  (exact match to decode; see "Versioning and unknown bits")
1   1   type   0=DATA 1=INV 2=WANT 3=ANNOUNCE
2   1   flags  b0 ENCRYPTED b1 SIGNED b2 FRAGMENT b3 ACKREQ b4 FLOOD b5 SRC8
               b6 RATCHET (0x40, §7)   b7 CANCEL (0x80, on WANT: §8)
3   1   hops   remaining relays (default 16; relays clamp incoming to ≤ 16)
4   4   created_at unix seconds u32 — when it was minted, not when it dies
8   8   dest   address | topic | 0x00×8 = public
-- if SIGNED: src = 32-B pubkey, or 8-B address if SRC8 --
    2   plen   u16
    N   payload
    64  sig    Ed25519 over all bytes above with hops zeroed
-- unsigned: no src, no sig; rides last everywhere --

The flags byte, bit by bit:

packet-beta
0: "b0 ENCRYPTED"
1: "b1 SIGNED"
2: "b2 FRAGMENT (retired)"
3: "b3 ACKREQ"
4: "b4 FLOOD"
5: "b5 SRC8"
6: "b6 RATCHET"
7: "b7 CANCEL"

Versioning and unknown bits. ver is an exact match: a decoder MUST reject any ver != 0x02 rather than guess, so a version change is a hard fork and not a negotiation. 0x02 is that fork. The header kept its shape — the four bytes at offset 4 are still four bytes at offset 4 — and changed their meaning, from a deadline the sender chose to the moment the envelope was minted. Left at 0x01 the two builds would still have refused each other, but by accident: a v1 expiry read as a birth time lands in the future, and a v2 birth time read as a deadline looks long expired. Both directions fail closed, which is luck rather than design. Flags are the extension point instead. Bits defined in v1 MUST be interpreted as named; a bit a node does not understand MUST be ignored, MUST be forwarded unchanged, and MUST NOT cause a drop. That rule is the agility hatch, and it has now been used twice without a version bump: b6 RATCHET and b7 CANCEL were both added to a shipped v1 wire. Forbidding unknown bits and relying on them for extension cannot both be true, and the forwarding rule is the one the code implements. All eight bits are now assigned, so the next extension needs either a retired bit — b2 FRAGMENT is spent, but reusing it would collide with envelopes older builds still emit — or a payload-level tag, which is where the file layer and §7 already put theirs.

ID = first 16 B of SHA-256(envelope, hops zeroed); computed, never transmitted (except inside INV/WANT/frag/ack). Zeroing hops is what keeps the ID stable while relays decrement the TTL.

Overhead: 114 B signed, 90 B SRC8, 18 B unsigned. SRC8 only toward peers that provably hold your key; relays never verify — endpoints do (see "Verify before binding trust state", Part II). No priority field: priority is bought, not claimed (§10 stamp).

3. Fragmentation — retired from the mesh, alive under the link

An envelope is never split end to end. A node emits exactly one envelope per message, and a hop too narrow to carry it splits it below the node and below the signature — link fragmentation (Part II) — reassembling at the far end of that same link. No fragment ever reaches the mesh, and no node other than the two ends of one link ever sees one.

There used to be a second, end-to-end form, and it is gone. The sender split once at its own MTU and only the destination reassembled. It could not repair the case it existed for: a fragment carries no nesting, so frames cut for a 1400-byte link died at the first 237-byte hop they met and no node on the path could fix it. It also flooded unsigned fragments across the mesh to solve a problem that is local to one link. Nothing emits it and nothing parses it; b2 FRAGMENT stays named so the bit is not reused for something that would collide with an envelope minted by an older build.

What replaced the size limit is a stated ceiling rather than a splitting rule. plen is a u16, so a payload is at most 65,535 bytes and the largest envelope on the wire is 65,649. Originating a message above that returns an error rather than silently truncating — which is what the encoder used to do, wrapping a 70,000-byte payload to a plen of 4,464 and producing a well-formed envelope containing the wrong bytes.

The coding below is retained, and still used — but by the link, not by the mesh: src/fountain.rs is what mints erasure-repair symbols for a hop-local fragment set, which is what lets a lossy narrow link recover without a return path. The payload shape described here is the historical end-to-end one.

payload = [orig_id:16][index:2][count:2][chunk]; all chunks equal size (pad the original; the envelope self-delimits). Fragments were ordinary envelopes (own IDs, same dest/created_at).

• index < count: plain chunk index of the original envelope's bytes.
• index ≥ count: repair chunk = XOR of the data chunks selected by the first count bits of SHA-256(orig_id ‖ index ‖ block), taken in 256-bit blocks numbered from zero; empty selection → chunk (index mod count). The sender can mint endless distinct repair chunks.

Both fields were one byte, which capped a set at 255 chunks. That bound the carrying size — 51 kB at a 237-byte frame — but it bound repair harder: one SHA-256 addresses 256 chunks, so a larger set had no repair at all and needed every piece. 255 pieces is under 12 kB on a 54-byte Zigbee frame, which is exactly where a lost piece is most likely. Hashing in numbered blocks lifts the ceiling to what the field can name.

Receiver decodes when any received set reaches rank count (Gaussian elimination over GF(2)); typically count+2 arrivals suffice at any loss rate, in any order, even one-way. Verify the reassembled signature; commit only what verifies.

Rateless — which is a property of the coding, not a promise about transfer. Nothing here needs a back-channel: a set can be received over a one-way link, off a torn sheet of paper, out of a CW transcript. What that buys is that an object whose symbols reach you decodes. It does not follow that a transfer completes one-way, and for the file layer it plainly does not: fetching is receiver-driven (§6), so a WANT needs a return path, and the sender never learns which symbols landed. Claim the coding, not the transfer.

Part II — Relay

4. Routing state (T2)

• Neighbors (per interface): point-to-point peers + anyone heard via hops=0 ANNOUNCE.
• Paths: addr → up to 3 of (iface, neighbor, age). Learned: (a) the first copy of any new signed envelope raced every path and won — its src is reachable via what delivered it; (b) flooded ANNOUNCEs. On broadcast media the interface is the direction. Fresh < 3 h; purge 7 d (stale entries still guide custody).

Path learning is local and non-transitive: a node believes only what it has personally received. The reference build advertises no third-party paths (np=0) and does not parse them on receipt, which bounds wormhole/eclipse to an attacker's own direct neighbours (Threat model ch. 5).

ANNOUNCE (type 3, signed): payload = [prekey:32][nt:1][topic×8 ea][np:1][(addr:8, age_min:2) ea][petname…] — your current encryption prekey (§7), topics you collect, and a path list. Link HELLO = hops 0; flooded = hops 16.

A node MUST accept any np the envelope can hold. A node MAY ignore the path list, and the reference build does: it always sends np = 0 and skips the field when parsing, so paths here are learned only from the first copy of signed traffic and from an ANNOUNCE's own src. Third-party path advertisement is reserved rather than implemented — turning it on is a Sybil and wormhole analysis, not a parser change.

5. Forwarding rules (the entire router)

flowchart TB
  RX["frame arrives on an interface"] --> FRAG{"starts 0xF6?"}
  FRAG -->|yes| REASM["link reassembly (Part II — the router never sees a piece)"]
  REASM -->|"set complete"| DEC
  FRAG -->|no| DEC["decode envelope: ver must be 0x02"]
  DEC --> CTRL{"type"}
  CTRL -->|"INV / WANT"| CONSUME["answer from the store, or adopt an interest. hops=0 · unsigned · consumed · never stored · never relayed"]
  CTRL -->|"DATA / ANNOUNCE"| SEEN{"id seen, or created_at in the future?"}
  SEEN -->|yes| DROP["drop. note: being *old* is not a reason to be here"]
  SEEN -->|no| MARK["remember the id · learn paths"]
  MARK --> MINE{"dest is mine, a topic I follow, or public?"}
  MINE -->|yes| DELIVER["deliver to the app (verify / decrypt per flags)"]
  MINE -->|no| STORE
  DELIVER --> STORE["store: keep it until the room is needed"]
  STORE --> HOPS{"hops > 0?"}
  HOPS -->|no| STOP["carry, but do not push. still delivered, still served on WANT"]
  HOPS -->|yes| FWD["decrement hops · forward on every other interface, inside the per-interface token bucket"]

flowchart LR
  MINT["minted: created_at = now"] --> ARR["arrives at a node"]
  ARR --> CHK{"created_at greater than now plus MAX_CLOCK_SKEW_SECS?"}
  CHK -->|yes| REJ["refused. the only normative check on created_at"]
  CHK -->|no| KEEP["kept, whatever its age"]
  KEEP --> FULL{"is the store full?"}
  FULL -->|no| IDLE["nothing asks how old it is"]
  IDLE --> FULL
  FULL -->|yes| RANK["eviction ranks it: past this node's max_relay_age first,
    then lowest stamp, then largest, then oldest arrival"]
  RANK --> GONE["evicted"]
  RANK --> STAY["survives this round"]
  STAY --> FULL

The only two moments created_at is read are the two boxes above: once on arrival, to refuse the future, and once under memory pressure, to order the victims. Between them an envelope's age is nobody's business.

1. Envelope arrives: ID seen, or created_at more than MAX_CLOCK_SKEW_SECS ahead of our clock → drop. Age is not checked here. Add ID. Learn paths (§4).
2. dest ∈ {my addresses, followed topics, 0×8} → deliver (verify/decrypt per flags). hops bounds push, not reach. A spent hop budget stops an envelope being relayed — sent onward unasked — and stops nothing else. The node still delivers it if it is a destination, still holds it, still lists it in an INV, and still serves it to a neighbour that WANTs it. That is deliberate and it is what store-and-forward is: the flood is bounded because one send must not buy unbounded transmission, while pull is bounded by demand instead, since every further step requires somebody to ask for it.

So an envelope at hops = 0 is not beyond reach, only beyond the flood. It is also the normal state of a file chunk, which is minted at hops = 0 (§8) and therefore never relayed by anyone — a node that discarded what it could not relay would never hold a chunk it had not published itself, and there would be no file layer.

3. Store it. Nothing expires; entries leave only when the room is needed, and only then is age consulted. Evict: past this node's max_relay_age → lowest stamp → largest → oldest arrival. TX order: local origin, then stamp, then FIFO.
4. Congestion control, four rules: (a) token bucket — a node MUST rate limit what it relays per interface, and SHOULD default to ≈10% of that interface's capacity (dedup makes dropped relays harmless); (b) Trickle timers — HELLO/ANNOUNCE interval doubles 5→80 min while nothing new is heard, resets to 5 on any novelty; (c) backpressure — HELLO carries one busy byte (queue fill); neighbors scale sending by (255−busy)/255 and defer unstamped relays to busy peers; (d) exponential backoff — FLOOD retries at 30 s ×2, cap 1 h, max 5.

The bucket is the rule; 10% is a default. What a relay owes its neighbours is a bound it can state and honour, not one particular fraction. The right figure depends on measured capacity, queue depth, loss, battery and how much custody the node has taken on — a node relaying half of a fast idle link is impolite, not non-compliant, and one relaying 10% of a duty-cycle-limited radio may already be over. The exception is regulatory: on ISM bands a duty cycle is law, and there the number comes from the regulator rather than from this document. Implementations should expose the budget as per-transport policy and keep the mechanism — bucket, backpressure byte, bulk budget — as the part that is not negotiable. 5. hops = 0 → stop. Else decrement, then: topic/0/FLOOD → damped flood on all interfaces (on shared media wait random 1–5× airtime, cancel if the ID is overheard ≥ 2×; ≥ 1× for directed) · unicast + fresh path → that interface/neighbor only · unicast, no path → silent, unless you hold custody and the path died: set FLOOD, continue. 6. Originator: no receipt (§8) → resend with FLOOD per 4d. Flooding is route discovery; replies teach reverse paths and heal blackholes. A receipt is the only delivery signal: overhearing your own envelope rebroadcast means the mesh took it, not that anyone received it, and MUST NOT clear a pending resend. 7. A wrong clock misjudges rule 1, and that is accepted rather than solved: a clock far in the past rejects current traffic, one far in the future accepts anything. It is the same failure such a node already has for every other time-based decision, and both alternatives are worse — trusting the sender puts the decision back with the attacker, and a "my clock is unreliable" flag is a switch the platforms that most need it are least likely to set. Fix the clock.

def on_rx(e, iface, nbr):
    if id(e) in seen or expired(e): return
    seen.add(id(e)); store.put(e)
    if e.SIGNED: paths.learn(addr(e.src), iface, nbr)   # first copy wins, keep 3
    if e.dest in my_addrs | topics | {ZERO}: deliver(e)
    if not e.hops: return
    e.hops -= 1
    if unicast(e.dest) and not e.FLOOD:
        p = paths.fresh(e.dest)
        if p: tx(p.iface, p.nbr, e)
        elif held_custody(e): e.FLOOD = 1; damped_tx_all(e)
    else: damped_tx_all(e)

6. Sync & custody (T1/T2)

On any meeting: ANNOUNCE, then INV (concatenated IDs, newest first, filtered by peer's topics + carriable unicast, and capped at MAX_IDS_PER_GOSSIP), peer replies WANT, send those.

"On any meeting" is a cadence, not an event. A node cannot observe that a neighbour has arrived — an interface coming up does not mean anyone is listening, and on broadcast media there is no event at all — so a node offers what it holds every INV_OFFER_SECS from its own tick, which covers arrival, reconnection and a neighbour that rebooted with one mechanism. A node holding nothing stays quiet.

Corrected. This paragraph used to say the INV was also filtered by a "per-neighbour watermark". Nothing implements one: build_inv filters by topic and by custody, and the term appears nowhere in the code. It was found by writing the glossary and trying to define it. A watermark is a good idea — re-offering a neighbour ids it has already declined is real waste — so it is now a roadmap row rather than a sentence describing something that does not exist. INV/WANT: hops=0, unsigned, consumed, never stored or relayed. Serving WANT is budgeted per interface, or it is a reflection amplifier.

A WANT payload is concatenated 16-byte ids, optionally followed by one trailing byte of remaining depth. Ids are 16 bytes, so an odd byte on the end is unambiguous; a WANT without one is a plain request and gets the default. That byte is what bounds recursive pull (Part III) — the envelope itself is still never forwarded.

Custody: push stored unicast to any peer that is the destination or announces a fresher path. A file or sheet of paper is concatenated envelopes; import = receive. Every boat, cyclist, or HF skywave contact merges two regions. That is the WAN.

Files are content-addressed: chunks [0x07][file_id:16][index:4][bytes], indexed by a signed manifest [0x01]…[chunk_id:16 × count] whose own ID is the shareable magnet. A manifest that outgrows one envelope nests — interior nodes [0x08][depth:1]… name manifests a level down, so the root stays one frame and one signature at any file size, and only the root is signed (an ID is the hash of its bytes, so the tree authenticates itself). Sealed to one recipient: [0x09][depth:1][hdr_id:16]…, where hdr_id names a separate object holding the file key and real name sealed to their prekey; each chunk is then encrypted under that key with the chunk index as nonce. The header is named rather than carried so a sealed root fits a small frame — inside the root it pushed the floor past 256 bytes, which no LoRa profile clears. See Part III for the layer built on this.

Link fragmentation — crossing a hop that cannot carry the frame

A bridge whose link has a smaller frame than the envelope splits it, and the far end of that same link puts it back. Below the node and below the signature: a fragment lives for one hop, is never relayed, and the router is never shown one.

[0xF6][set:2][idx:2][count:2][piece …]        7 bytes

packet-beta
0-7: "0xF6 — not 0x01, so it is not an envelope"
8-23: "set (u16)"
24-39: "idx (u16)"
40-55: "count (u16)"
56-183: "piece — a slice of whatever envelope is crossing this hop"

This is link framing, not wire. A fragment never leaves the link, so its shape is a bridge's business the way KISS is, and it is not part of Part I. That is what makes it cheap: seven bytes against the thirty-six §3's end-to-end header costs, which on a 54-byte Zigbee frame is 47 usable bytes per fragment instead of 18. 0xF6 is the discriminator because an envelope's first byte is VER = 0x01, so a receiver tells the two apart without being told and a peer that never fragments is unaffected.

Repair symbols. An envelope cut into n pieces arrives only if all n do, so a link dropping 10% of frames loses about 46% of fragmented envelopes. A sender MAY therefore send index ≥ count repair symbols — the same erasure code as §3, so any n of the n+r sent reconstruct. Measured over 200 trials of a 900-byte envelope on a 237-byte frame — five pieces — one repair symbol takes 10% loss from 54% delivered to 66%, two to 87.5%, and four to 99.5%. These supersede an earlier set claiming 90% for one symbol and 96% for two; those were recorded once and never re-run, and the scenarios behind them are reported rather than asserted, so the drift went unnoticed. Repair buys a great deal, but one symbol is not enough at 10% loss, which is why the amount is now derived from the measured loss rather than fixed at a quarter. Repetition instead of a code manages 70% for the same redundancy, because a duplicate only helps if it lands on a gap.

How many is local policy — the sender picks, the receiver decodes whatever arrives, and the two never agree on a number. The default is a quarter of the set, which costs nothing on a link wide enough never to fragment. Repair needs no return path, which is what makes it usable on a one-way radio or a shared channel where a NACK would collide with the traffic it complains about.

Bounds. Reassembly is a place a neighbour allocates memory unasked, so it obeys the resource invariant like everything else: a cap on open sets, a cap on bytes, a timeout, and accounting per key so one loud peer cannot evict another's half-finished frame. The key is the neighbour where the medium has addresses and the interface where it does not — on a broadcast medium two senders can collide on a set id, so a set that reassembles into something that is not an envelope is dropped rather than parsed.

Interaction with the node's own MTU: none. A node keeps its MTU whatever its links are. Clamping it to the narrowest attached link — which this implementation did — only ever helps a node that owns the narrow link, and never a node upstream of one.

Bindings — SPORE on everything

flowchart LR
  R["the router: one wire format, unchanged"] --- BR["a bridge per medium"]
  BR --> S1["1. message pipe"] --> M1["UDP, BLE, LoRa, Meshtastic, iroh"]
  BR --> S2["2. byte stream"] --> M2["TCP, serial, Bluetooth RFCOMM, Tor, I2P"]
  BR --> S3["3. text channel"] --> M3["email, SMS, IRC, paper, voice"]
  BR --> S4["4. shared bus"] --> M4["packet radio, CB, half-duplex RF"]
  BR --> S5["5. shared store"] --> M5["a folder, a USB stick, S3, copyparty"]

Every medium on Earth has one of five shapes. Bind by shape; the router never changes. This section is normative for the shapes; the per-medium parameter tables (frequencies, port numbers, UUIDs, MTUs, firmware caveats) are the manual, Bridges.

1. Message pipe → one envelope/fragment per message.
2. Byte stream → KISS: frames delimited 0xC0, escape 0xC0→0xDB 0xDC, 0xDB→0xDB 0xDD, command byte 0x00.
3. Text channel → armor: ~S1. + Base32(envelope) + . + Base32(SHA-256[0:4]) + ~, whitespace ignored.
4. Shared bus → KISS + CSMA: listen-before-talk, backoff 1–5× airtime; no native CRC → append SHA-256(envelope)[0:4], verify or drop.
5. Shared store → write envelopes as entries named by hex ID; reading = receiving; the store is a persistent INV.

In this implementation those five collapse to three driver forms — dgram, stream, store — because a message pipe and a shared bus differ only in whether you listen before talking, and a text channel is a byte stream with an armor codec.

Underlays with their own routing = ONE interface. Meshtastic, Reticulum, Yggdrasil, cjdns, BATMAN/OLSR, Tor/I2P, WireGuard, plain IP — each already moves bytes across many physical hops. Hand it one frame and decrement hops once for the whole crossing; its internal hops are invisible and free. Point-to-point backbone links may restore the hop so long hauls don't burn the budget. SPORE hops therefore count gateways between networks, not hops inside them — exactly IP over Ethernet. They are transports SPORE rides, not rivals.

Numbers worth memorising. Port 7373 (UDP/TCP/WS), the same value as EtherType 0x7373 and multicast 239.73.73.73 / ff02::7373. Meshtastic portnum 256. BLE rides the Nordic UART Service (6e400001-…, RX …0002, TX …0003) rather than a SPORE-specific UUID — it is what phones, hobby boards and RNodes already expose. Everything else: look it up.

Two address spaces. Who = the SPORE address or topic — end-to-end, cryptographic, identical on every medium. How = the underlay's own naming (a node number, a destination hash, an IP:port, or nothing at all) — local to one link. A bridge owns exactly one interface and translates between them; the router never learns underlay addresses, the way an OS's ARP table maps IP→MAC. Bindings are learned by snooping signed frames — a signed envelope proves its own sender, so no handshake is needed — and a stale binding costs nothing, because flood-fallback (§5.6) routes around it.

A link may declare a bulk budget. Since files are manifest trees they can be arbitrarily large, so any link can be conscripted into hauling one. An interface may cap bytes/second of other people's file chunks it will relay. Only chunks count: messages, announces, receipts and manifests always pass, so a paced link stays a full member of the mesh — it still carries the conversation and still tells everyone what exists. It declines only to be the pipe, and because chunks are named by content the fetch just asks again and another path answers.

Zero-rendezvous peering (browsers & phones). A WebRTC session reduces to ufrag(4) + pwd(22) + DTLS fingerprint(32) + mDNS host candidate(16) ≈ 90 B; both sides rebuild full SDP from a hardcoded template. Beep that descriptor over ultrasound or show it as a QR, answer, and the browser's own mDNS completes a direct DataChannel — no server, no typed IP, ≈15 s. Native nodes run ice-lite with static ufrag/pwd/fingerprint, so their descriptor is a constant you can print on the box — specified, not built: WebRTC here is browser-only, so the native half is a Roadmap item.

App distribution: a native node's HTTP bridge exposes the bag API — POST /spore/push, GET /spore/inv, POST /spore/want, MIME application/x-spore — on port 7373, to localhost and to the LAN at its IP. Serving the PWA itself from / is the intended end state (the app store is every node) but is not implemented: bridge::bag routes the three bag paths and 404s everything else.

Verify before binding trust state

§2 says relays never verify. That is about the cost of forwarding — a relay moves bytes it cannot read toward a destination it is not, and checking a signature on every envelope in transit would tax the smallest nodes for a guarantee the endpoint provides anyway. It is not a licence to write unauthenticated claims into local state. A relay keeps three tables an attacker would like to choose the contents of:

All three once accepted the SIGNED flag as proof — one bit chosen by whoever wrote the frame — so all three were forgeable with a copied public key and 64 zero bytes (S-002, S-004). The rule is therefore narrower than "relays verify" and wider than "relays never verify":

Verify before binding trust state; do not verify to forward.

The cost is bounded on purpose: one verify per newly-seen signed envelope, reused across all three tables and run only after dedup and the post-dating check, so replays and stale mail are dropped before any crypto. On an ESP32 relaying LoRa that is a real per-envelope cost, accepted knowingly — a relay that can be told a false address is worse than a relay that is slower.

The resource invariant

Every bound in this part is one idea, applied in as many places as a stranger can push on:

No remote node can cause another to transmit, store, or process an unbounded amount without continuing evidence of demand, or an explicit bounded local allowance.

Both escape clauses are load-bearing. Continuing evidence of demand is why a WANT names ids and is answered once rather than subscribing a peer to a stream: the asking is the authorization, and it has to be repeated. Explicit bounded local allowance is why a node may hold custody for strangers at all — the operator set a budget, and a peer may fill it but never exceed it.

Three of these are the general form, and an implementation should be able to point at all three: an object's welcome (this node's max_relay_age against the envelope's created_at — a local opinion, consulted only when the store is full), a transfer allowance (a bounded request, or a lease), and a transport budget (the token bucket and backpressure of §5.4). Transmit only while all three still hold.

The first of those used to be the sender's to set, and moving it is the point of M12. A sender wrote a deadline and every relay honoured it, which let a stranger reserve a week of somebody else's storage — precisely what the invariant above forbids everywhere else. An envelope now states a fact about itself (when it was minted) and each node decides what to do about it.

sequenceDiagram
  autonumber
  participant A as Alice's phone
  participant P as a phone in the crowd
  participant C as a courier
  participant B as Bob
  Note over A,B: nobody negotiates any of this. one node has a larger number.
  A->>P: envelope, minted today
  Note right of P: max_relay_age one day. the store fills, and this is the oldest thing in it
  P--xP: evicted after a few days
  A->>C: the same envelope
  Note right of C: max_relay_age thirty days. its store fills too, but this is not old to it
  C->>C: carried, out of range, for a fortnight
  C->>B: still holding it
  Note over A,B: the envelope never knew it was being couriered

A courier is a setting, not a feature. Because age is a local preference rather than a wire property, a node that raises max_relay_age simply keeps old envelopes when others have thrown theirs out, and hands them on to whoever it meets. Nothing new is negotiated, no envelope knows it is being couriered, and a node that does this is not distinguishable on the wire from one that does not. Measured: at one day's tolerance a carrier under storage pressure kept 1 of 30 ten-day-old envelopes; at a month's, 15 of 30.

Two rules that are easy to get wrong, and were:

• Enforce after the write, not only before it. A ceiling checked at the start of handling a frame leaves every table one entry over until the next frame arrives — which, on a link the attacker controls, is indefinitely.
• Charge a shared budget to the interface that caused the growth, never to a global pool, or the loudest link evicts the quietest one's work.

Part III — Endpoint profiles and local policy

7. Crypto & forward secrecy

flowchart TB
  M["a message for one recipient"] --> K{"do we have a ratchet session with them?"}
  K -->|no| PK{"have we heard their ANNOUNCE?"}
  PK -->|yes| SEAL["one-shot seal to their newest prekey. zero per-message state"]
  PK -->|no| CLEAR["send in the clear, and say so in the UI.<br/>silence would be worse than honesty"]
  K -->|yes| RAT["ratchet: ENCRYPTED + RATCHET (b6)"]
  SEAL --> BOOT["both sides having each other's prekey is itself the handshake:<br/>a static-static DH gives both the same root, with no round trip"]
  BOOT --> RAT
  RAT --> FS["forward secrecy: a key that opened yesterday's mail cannot open today's"]

The path a message takes through this depends only on what the sender already knows about the recipient, and never on a negotiation — there is nowhere to hold one.

• Sign: Ed25519 (§2).
• Seal (baseline, one shot): libsodium crypto_box_seal to the recipient's newest prekey (X25519, from ANNOUNCE, signed there). Zero per-message state. Implementations MUST hold a prekey ring (§7.2).
• Sessions: Double Ratchet. Set RATCHET (b6) on an ENCRYPTED DATA envelope whose payload is ratchet-shaped rather than one-shot-sealed.
  • Bootstrap, no handshake: when both sides know each other's current prekey (i.e. after ANNOUNCE), each derives the same root from a static-static X25519 DH — own current prekey secret × peer's advertised prekey public. The numerically lower address is the pair's initiator, with a sending chain immediately; the higher is the responder and has no sending chain until it receives the initiator's first ratchet message, so its own earlier sends go as plain one-shot seals.
  • Bootstrapped once per peer, never re-seeded from a later ANNOUNCE. Implementations MUST settle a due prekey rotation before both building an ANNOUNCE and bootstrapping from one, or the two sides derive different roots.
  • Sessions are local state and need not persist; a restart may lose one and re-bootstrap from the next ANNOUNCE.
  • Payload: [dh_pub:32][n:2][pn:2][ct], ct = ChaCha20-Poly1305(mk, nonce=n, ad=header). On a new dh_pub: root,ck_in = KDF(root, DH); on a fresh ratchet key: root,ck_out = KDF(root, DH). Each mk = KDF(ck), then dropped. KDF = BLAKE2b. A ratchet turn reseeds the chains with new entropy, which is what recovers from a compromise.
  • Skipped mks are cached for out-of-order arrival, bounded by both count (MAX_SKIPPED_KEYS) and age, and zeroised on drop. The age bound is the same configured value as the prekey lifetime (§7.2) — one knob, so the two windows cannot disagree.
  • Compromise leaks nothing older than one ratchet turn.
• Encrypted topics: pre-shared key, XChaCha20-Poly1305, 24-B nonce prefixed. Rotation: flood KEYROT <newpub> signed by the old key.

7.1 Topic key schedule

rotate(k) = SHA-256(k ‖ "spore-keyrot-v1") advances an epoch: forward secrecy, but a stolen key follows the chain, so it never heals.

Healing rotation: draw 32 random bytes c, seal a copy to each member's prekey, everyone folds it in with mix(k,c) = SHA-256("spore-topic-mix-v1" ‖ k ‖ c). Message = [0x01][count:2 BE][80-B sealed box]×count, no recipient hints (so it does not enumerate the group); a member trial-decrypts, ≤ 256 boxes. Mix, never replace — so an attacker able to sign as a member cannot cancel an honest contribution, only append steps to a chain one unreadable step has already made unknowable. That is post-compromise security: the group heals by operating, with no detection step.

key_id(k) = SHA-256("spore-topic-keyid-v1" ‖ k)[..4] names a key so a receiver holding several candidates picks the right one. The group has no roster and no arbiter: members can diverge, and key_id makes divergence readable rather than fatal.

7.2 Prekey ring

Up to 16 prekeys, oldest first; the newest is advertised in ANNOUNCE. Mint one every 24 h and delete any secret older than the configured lifetime (the "offline window", default 7 d); the newest is never deleted, so a node is always sealable. Opening tries every live entry newest-first, so a sender who last heard an older ANNOUNCE still reaches you until that secret expires. The nonce mixes the recipient's public key, so an entry stores both halves.

The requirement that makes it mean anything: prekey secrets MUST be random and MUST NOT be derivable from the identity seed. Restoring from a seed recovers the address, the signing key, and the ability to mint new prekeys — it MUST NOT recover a deleted secret, or "delete" has no referent.

Consequences, each a real cost: seed() alone is not a whole backup (persist the ring beside it, or the restored node has no forward secrecy and cannot read mail sealed to anything it had rotated to); mail sealed to an expired prekey is unreadable by everyone, including you — that is the feature, not data loss; and a backup of the ring defeats the offline window, as it would for any forward-secret keystore.

8. Receipts (ACKREQ)

Recipient floods a signed DATA to src, payload = 0x06 + orig ID. ACKs also teach reverse paths. A receipt MUST be verified as signed by the destination it claims to come from: the ID it references is public (it rides in every INV), so accepting on payload shape alone lets any stranger forge "delivered" (S-032).

The sender re-floods an unacked message on the §5.4d backoff — flooding is route discovery, so a resend can find a path a blackhole was hiding — and gives up after the cap. Known simplification: a lost receipt is not re-requested, since a duplicate of the original is deduped before it could re-trigger one.

9. Anonymity — mix mode

An onion is nested sealed envelopes. Sender picks 2–3 relays that follow topic mix (learned from ANNOUNCEs) and wraps inside-out: each layer = an envelope addressed to one mix, payload sealed to it = 'O' + the next full envelope. A mix decrypts, waits a random Poisson 1–30 s, batches ≥ 3, re-injects the inner envelope as its own traffic.

• Sender anonymity: leave outer layers unsigned; sign only the innermost if at all.
• Recipient anonymity: innermost dest 0×8, payload sealed — everyone carries, one can open.
• Unlinkability: pad every onion payload to size classes 256 / 1024 / 4096 B so depth never shows; mixes SHOULD emit Poisson decoy onions at roughly their real rate.

Honest limit: beats local observers and any subset of mixes; a global passive observer is only beaten while decoy traffic flows. Mix mode is opt-in and never silent — confidential is not the same as anonymous.

10. Self-defense (local policy)

Everything here is local policy: a node's own choice, never negotiated, never a wire change.

Stamp — the only cross-node priority. n leading zero bits of an envelope's ID = class n, mined by grinding a nonce in the payload. Priority is therefore bought, not claimed: there is no priority field to forge (§2), and the proof is the ID, so any node verifies it with one hash, no state, on every medium. Each class costs 2× the last. The stamp drives TX order and eviction order (§5.3), and gates the §5.4c backpressure bypass — which requires at least 16 leading zero bits, not merely a non-zero stamp, since class 1 is about two hashes' work and would let anyone ignore a busy peer for free.

What the stamp does not do: it prices one envelope. It is not bound to an identity, so it says nothing about how many identities an attacker mints — it is not Sybil resistance, and nothing here claims to be. It raises cost; it does not cap it.

Quotas. Per-source and per-topic byte budgets, applied whether or not a frame is signed. Unsigned mail rides last.

Trust. Prefer keys you have met or your operator vouches for; confirm a peer out of band by address emoji-hash. No topic is privileged: there is no string a sender can choose that buys priority, quota, or a relay it would not otherwise get.

11. Defaults

hops 16 · default max relay age 7 d · MTU 1400 · HELLO 5→80 min Trickle · ANNOUNCE flood ≤ 1/h · path fresh 3 h · seen-set ≥ 30 d received · prekey mint 24 h, offline window 7 d · relay airtime rate-limited, ≈10% default · payload UTF-8. T0 ≈ 60 lines; full T2 ≈ 400 with libsodium.

Link and file defaults, all local policy: link fragment repair ¼ of the set (min 1) · half-finished link set dropped after 30 s · chunks pushed with a manifest 8 · adopted-interest lease 15 min (cancel is the fast path) · WANT recursion depth 8.

Known limits, on purpose: no stream semantics; an envelope is at most 65 535 payload bytes, because plen is a u16 — larger objects ride the file layer (§6), bounded by storage and by what each link agrees to carry rather than by a fragment count; no permanence (nodes discard their oldest cargo, by design); mix-mode anonymity needs flowing decoys to beat a global observer; ratchet state is per-device — give each device its own key.

That envelope ceiling used to be ≈50 KB, set by a one-byte fragment count. Both fragment counts are u16 now, so the payload length is what binds — and it binds at the same place for every link, rather than at a different place for every frame size.

What stops what

Every mechanism above answers a specific adversary. This is the index; the full analysis, with a residual-risk line on every row, is Threat model.

Not solved, stated plainly. Identity-key revocation: none exists; a stolen signing seed is trusted until people stop trusting the address out of band. Sybil resistance: nothing counts identities today. A hostile relay simply dropping traffic: bounded by redundancy, never prevented — you cannot cryptographically force a relay to forward. Jamming and physical-layer denial: out of scope at this layer.

Application layer

The one rule this part is built on: nothing here touches relays. Every feature below is a payload convention plus endpoint state — never a change to what a relay must understand. That is what keeps a 200-byte LoRa packet, a QR code, or a human reading armor aloud a first-class peer: a relay parses the fixed header, dedups, stores and forwards, and nothing else. A feature requiring relay support would have to be rolled out to every medium in lockstep.

App tags — how endpoints tell payloads apart

The frozen header has no port or content-type field. The first payload byte is the app tag, read only by the destination.

Fragments are the one exception: recognised by the FRAGMENT header flag rather than a tag, and their chunk is a slice of an ordinary already-tagged inner envelope, so tags and fragmentation compose cleanly.

Every service maps onto one of four patterns — objects, sessions, request/response, feeds — each already a mechanism or a payload convention. Note what is deliberately absent: a raw reliable byte-stream offered by the network. A stream assumes a live, low-latency, bidirectional path, the one thing an opportunistic network cannot promise. Reliability exists, but as an endpoint concern — exactly how QUIC builds it on UDP without the network knowing.

Objects — send anything, any size

send(dest, data) takes any size, up to the 65 535 bytes plen can describe; larger data is the file layer's job. Under the sender's MTU it is one envelope.

Over it, two things could happen and only one should. What crosses a narrow hop is link fragmentation (Part II): the bridge splits for its own link, the far end reassembles, and the router never sees a piece — so a frame reaches a 237-byte radio three hops away without the sender knowing that radio exists. The end-to-end form in §3 also still triggers here, splitting once at the sender's MTU, and it is redundant: its fragments cannot be re-split, so on their own they die at the first narrower hop. Retiring it is outstanding work.

What survives a one-way link. A fountain set does, because enough symbols arriving is the whole condition. A file does not: its chunks are pulled with WANT, so every hop needs a return path at some point — though not at the same moment, since a request may be held and served at a later meeting. So a magnet and a handful of chunks can travel one-way on paper; a swarm cannot. Carrying a whole store one-way does move a file, because that is a push and needs no request — but it is not the same claim, and the difference is exactly a back-channel.

Files — magnets, trees, swarming

A manifest is a signed envelope naming a file's size and its chunks' content IDs; its own ID is the shareable magnet (spore:<hexid>, armor, or a QR). Chunks are fetched from whoever has them and each verifies itself on arrival.

manifest = SIGNED [0x01][file_id:16][chunk_size:4][count:4][total_len:8][name][chunk_id:16 × count]
interior = UNSIGNED [0x08][depth:1][file_id:16][chunk_size:4][count:4][total_len:8][name_len:2][id:16 × count]
sealed   = SIGNED [0x09][depth:1][hdr_id:16][file_id:16][chunk_size:4][count:4][total_len:8][name][id:16 × count]

Manifest trees. One manifest is one envelope, so it can only name so many chunks — about 93 KB of file at a 1400-byte MTU. Past that, chunk IDs are grouped under interior manifests, and those grouped again, until what remains fits the signed root. At depth == 0 the IDs name chunks; at depth > 0 they name manifests of depth - 1. Capacity multiplies by the interior fan-out (~84) per level, capped at MAX_DEPTH = 4:

A file that fits one manifest encodes exactly as it did before trees existed, so nothing that already works changes.

A sealed root names its header rather than carrying it. The header — an ephemeral key, an AEAD tag, the file key and the real name — is about 82 bytes, and inside the root it sat on top of the root's own 114 bytes of source key and signature. That put a sealed root past 256 bytes before it could name a single chunk, which made sealed publishing impossible on every LoRa profile: one byte over raw LoRa's ~255-byte frame, nineteen over Meshtastic's 237. Naming it costs 16 bytes and brings the floor to 188, which every LoRa profile clears.

The header is an ordinary object on the file's topic, link-local like a chunk, and it travels with the root — it is small, and nothing else in the file is any use without it. A recipient that holds the root but not the header is in the same state as one missing a chunk, and asks for it the same way.

Pushing the first chunks (local policy). A publisher MAY send a few chunks alongside the manifest, so a file small enough to fit that budget arrives complete and costs no round trip. The receiver's behaviour is identical either way — it ignores what it holds and WANTs the rest — so the two ends never agree on a number and 0 is a legal setting. Counted in chunks, not bytes, so it scales with the link: eight chunks is about 10 kB at a 1400-byte MTU and 1.4 kB over LoRa, where a byte threshold would push 10 kB onto a radio and call it small. Sealed files are not pushed; they are addressed to one recipient.

Fetching across more than one hop (endpoint profile, not a wire rule). A node MAY adopt a neighbour's WANT as its own for ids named by a manifest it holds, subject to depth, lease, fanout and bulk budget. It MUST NOT forward the WANT envelope. Chunks return by the same one-hop serve path and MAY be cached.

That sentence is the whole of multi-hop file transfer, and every clause in it is load-bearing. Adopt, not forward keeps §6's bound intact — WANT stays hops=0, unsigned, consumed, never relayed — while still letting demand walk: the relay is not carrying someone else's request, it has acquired an interest of its own. Named by a manifest it holds is the authorization: the flooded root is what made the file legitimate to ask about, and the tree names every legal child, so a want-id nobody has a manifest for starts no hunt. Cached, not pinned keeps a popular magnet from filling the mesh's stores.

Depth rides as one trailing byte on the WANT payload — ids are 16 bytes, so an odd byte on the end is unambiguous, and a WANT without one is a plain request getting the default budget. Each adopting hop decrements it; at zero a node answers from its own store or says nothing.

A node MUST clamp the incoming depth to its own default rather than honour what the frame claims. The byte arrives unsigned from anyone in range, and it is the only one of this section's three bounds that the asker supplies: the manifest gate and the interest table are both checked locally, but reach was whatever the stranger wrote. Measured on a 24-node line: an honest depth of 8 leaves 8 nodes holding an interest, a forged 255 leaves 23 — one frame, and every one of those interests is a multi-day obligation that is re-stated on a cadence. Clamp rather than reject, because a relayed WANT legitimately carries a decremented depth: asking for less is normal and must keep working, and only claiming more is refused.

Fanout is bounded by the interest table rather than by a neighbour count. A node asks on every interface except the one that asked it, but a node that already holds a live interest in an id records the new waiter and stays quiet — so total traffic is linear in the nodes reached, not exponential in the paths to them. That is the pending-interest-table argument, and it is what makes depth 8 safe on a node with several links.

stateDiagram-v2
  [*] --> Idle
  Idle --> Adopted: a neighbour WANTs an id we lack,<br/>and a manifest we hold names it
  Adopted --> Adopted: another neighbour wants it too,<br/>so it joins the waiter list and we stay quiet
  Adopted --> Served: the object arrives
  Served --> [*]: handed to every waiter, then forgotten
  Adopted --> Retired: last waiter cancels, or its link drops
  Retired --> [*]: cancel emitted onward, unwinding the path demand took
  Adopted --> Lapsed: deadline passes
  Lapsed --> [*]: the backstop, for a waiter that could not say goodbye
  Adopted --> Restated: persisted, carried, and spoken somewhere new
  Restated --> Adopted

Five ways out and only one of them is the timer. Served is the ordinary case; Retired is M11-K and is the fast one; Lapsed is the backstop; Restated is M11-P, the interest that survived a journey.

The lease is scoped to the object, not to a timer (M11-P). An adopted interest lives as long as this node would still be carrying the manifest that named the id — its created_at plus our own max_relay_age, clamped into [now + 900 s, now + 7 days] — because the chunks being hunted for die with the the same pressure as everything else, and an interest that outlives them is hunting for bytes nobody will serve. A fixed short lease made adopted interest an online-only mechanism inside a store-and-forward protocol: a courier who takes a day to reach the next mesh had forgotten what it was carrying long before arriving.

Lengthening a remote-caused commitment is safe only because three bounds hold it, and an implementation MUST keep all three: the deadline is read from a signed manifest whose birth time the asker does not control, and by a policy that is ours and not theirs; the number of simultaneous interests is capped locally; and cancel retires one as soon as its last waiter leaves.

An interest MAY be persisted and restored, which is what lets a request cross an offline leg. Restored entries carry no waiters — an interface index means nothing after a restart — and a node MUST drop any that are already expired or past the ceiling it would have set itself, so a blob cannot mint a promise the node would not have made. A node holding interests SHOULD re-state them on a slow cadence (the reference build: every 5 minutes), since a WANT is otherwise only emitted when a neighbour asks, and after a journey the neighbour who asked is gone.

sequenceDiagram
  autonumber
  participant A as Alice (wants it)
  participant B as relay
  participant C as relay
  participant S as seeder
  Note over A,S: the root already flooded, so everyone can name the parts
  A->>B: WANT ids (depth 8)
  Note right of B: holds none, but a manifest it holds names them, so it may adopt
  B->>B: adopt interest, waiter is A
  B->>C: WANT ids (depth 7) — B's own request, not A's relayed
  C->>C: adopt interest, waiter is B
  C->>S: WANT ids (depth 6)
  S-->>C: chunks
  Note right of C: caches what it carried
  C-->>B: chunks (directed at the waiter, not flooded)
  B-->>A: chunks
  Note over A,S: a second fetcher on this path is now served by B or C

  A->>B: WANT + CANCEL (or the link drops)
  B->>B: last waiter gone → drop interest
  B->>C: CANCEL — the unwind follows the path the demand took
  C->>C: last waiter gone → drop interest

Cancel is the other end of the lease. An adopted interest is a standing obligation, so a relay whose last waiter has gone keeps asking every seeder in range until the lease runs out — fifteen minutes of load nobody wants. A node that no longer wants an id SHOULD say so with a WANT carrying CANCEL (b7), and a node MUST treat that as removing only the sender's own waiter. When the last waiter for an id leaves, the interest is dropped and the node SHOULD emit its own cancel onward, so the unwind follows the same path the demand did. A receiver that cannot say goodbye — out of range, powered off — is covered by the lease as before, and by its neighbour retiring the interests that link was the sole waiter for.

A flag rather than a new envelope type, deliberately: INV and WANT are consumed before anything else, so a node that does not know b7 still treats the frame as a WANT — consumed, never stored, never relayed. A new type would fall through to the store-and-forward path, which is the one thing a one-hop control message must never do. The cancel carries no depth byte, so its payload length stays a multiple of 16.

Cancel cannot be turned into an attack. It only ever removes the sender's own waiter, so a hostile neighbour cancelling ids it never asked for changes nothing for anyone; the onward cancel is emitted only where an interest actually died, so n ids in produce at most n out, once — a replayed cancel finds no interest and stops. Unlike a WANT it can only shrink state, so it needs no admission check.

This is a Part III profile because it changes what an endpoint chooses to ask for, not what any envelope looks like. T0 is unchanged: receive → dedup → store → deliver → forward.

• Chunks are a static size, fixed by the protocol (M11-M): CHUNK_BYTES, 4 KiB, the same for every publisher on every medium. It used to be mtu - 64, which was a leftover from before link fragmentation, when a sender had to cut for the narrowest hop it might meet because nothing downstream could re-cut. After M11-D the only thing publisher MTU still decided was that a Wi-Fi node and a LoRa node cut the same file differently and therefore shared no content ids — which defeats content addressing as thoroughly as a random file_id would. Identical bytes MUST produce identical chunks for everyone.

  flowchart TB
    subgraph FILE["file layer - Part III - travels the mesh"]
      direction LR
      F["a 10 KB file"] --> C1["chunk 0: 4096 B"] & C2["chunk 1: 4096 B"] & C3["chunk 2: 1808 B"]
      C1 -.-> M["manifest names the content ids, in order"]
      C2 -.-> M
      C3 -.-> M
    end
    subgraph LINK["link layer - Part II - never leaves one hop"]
      direction LR
      C1 ==> P1["piece 0"] & P2["piece 1"] & P3["piece n"] & PR["repair symbol"]
      P1 --> R["far end reassembles the envelope"]
      P2 --> R
      P3 --> R
      PR --> R
    end
    R ==> OK["router sees one envelope, and never saw a piece"]

  A chunk is not a fragment, and neither is derived from the other. A chunk is a file-layer object: content-addressed, one fixed size everywhere, the unit a manifest names and a WANT asks for. A fragment is a link-layer artefact: sized by one hop's MTU, carrying whatever will not fit that hop — a chunk, or any other envelope — and reassembled at the far end of that same link. Chunks are therefore routinely larger than a frame, which makes per-hop splitting a dependency of the file layer rather than an optimisation: a transport that cannot split cannot move files.

  4 KiB is chosen against the smallest node, not the largest file: a minimal profile floors link reassembly at 16 KiB, so four chunks fit its buffer at once, and a 1 MB file is 256 ids rather than the ~6000 an MTU-sized chunk needed on LoRa (chunk-fragment-ok: the rejected sizing). chunk_size in a manifest is exact — every chunk but the last is that size — so a reader may compute which chunk holds a given byte.

  What this gives up: boundaries are offsets from the start of the file, so inserting a byte shifts all of them and an edited file shares nothing with its predecessor. Appending shares everything. Content-defined boundaries would fix the insert case at the cost of variable-length chunks and losing the offset property; the choice here is static.

• Every field a stranger can set has a ceiling (M11-N), and the interesting part is which of them needed one. count was already checked against the bytes that follow, so a manifest cannot make a decoder reserve for parts it did not send. Depth was already capped at MAX_DEPTH, and a child is read only if it decodes at exactly parent.depth - 1 — so a tree cannot walk sideways, and cannot walk in circles at all, since naming a cycle would require a manifest to contain its own hash.

  total_len was the one taken on trust. At depth 0 it is exactly checkable — every chunk but the last is CHUNK_BYTES — so a leaf claiming more than its chunks could hold is now refused. That is not cosmetic: assembly compares bytes written against it, so a file claiming more than it can ever deliver is a file that is permanently incomplete, and an incomplete file reserves pinned store (M12-A) and keeps an adopted interest alive (M11-P). One forged field otherwise bought a permanent resident.

  Interior nodes cannot be checked on arrival — the subtree their total_len covers is not in the payload — and inherit the bound transitively instead, because every leaf beneath them is checked as it arrives.

  What a relay does with an oversized envelope is split it, not drop it. That is worth stating because the obvious ceiling to add here would be "relays drop what is too big", and it is precisely the M11-D bug: a relay's own frame size is not a property of the envelope crossing it.

• Content ids, not envelope ids (M11-M). A manifest names the content id of each part: the first 16 bytes of SHA-256 over the part's payload, and nothing else. This is deliberately not the envelope id, which hashes the whole envelope and so covers created_at and dest — right for a message, wrong for bytes. Conflating them meant a byte-identical file published twice shared zero of sixteen envelopes with itself, because a chunk carried a random per-publish file_id. A chunk payload is therefore [CHUNK_TAG][bytes] with no file or index field: the manifest already says which parts are this file and in what order, and a sealed part's AEAD nonce is its position in that order, which the reader counts while walking rather than trusting the payload to state. A node MUST be able to resolve a named content id to whichever stored envelope carries it, and a WANT may name either kind.

• Integrity is free. The root is signed, and every ID below it — chunk or sub-manifest — is the hash of the bytes it names, so a forged or corrupt part simply never matches. Only the root is signed: the hash chain covers the rest, which is why interior nodes need no signature and buy back ~96 bytes of fan-out each. The magnet is a genuine Merkle root.

• Swarming is just WANT. Only the small root floods; everything else is pulled. fetch(magnet) emits a WANT for the IDs it lacks and any peer holding them answers from its store — the existing §6 machinery, untouched. Multi-source and resumable, because parts are named by content, not by origin.

flowchart TB
  ROOT["root manifest: signed, flooded, its id is the magnet"] --> I0["interior, unsigned"] & I1["interior, unsigned"]
  I0 --> K0["chunk"] & K1["chunk"] & K2["chunk"]
  I1 --> K3["chunk"] & K4["chunk"] & K5["chunk"]
  ROOT -.-> HDR["sealed files only: header object holding the file key and real name"]

Only the root is signed and only the root floods. Every id beneath it is the hash of the bytes it names, so a parent authenticates its children and interior nodes need no signature — which buys back ~96 bytes of fan-out each.

• It resolves top-down. A WANT frame holds ~86 IDs, and deeper levels are not even nameable until the levels above arrive, so fetch returns one frame's worth per call and is called until complete.

Sealing to one recipient. [0x09] roots encrypt each chunk on its own under a per-file key and seal that key, with the real file name, into the root's header. The key is fresh per file, so the chunk index is a safe nonce and costs 24 bytes less than a random one — leaving only the 16-byte tag, which the chunk size already had room for, so a sealed chunk rides exactly the frame an open one does. The recipient decrypts a chunk at a time straight to disk, so a sealed file costs one chunk of memory rather than all of it. Relays learn neither contents nor name; interior manifests carry only hashes and are never sealed.

What bounds a file is not the wire format: every chunk lives in the store, so the ceiling is half the store budget (leaving the other half to relay with), and beneath that whatever the slowest bridge on the path will carry.

Folder sync turns each file in a directory into a manifest on a folder-topic; a subscriber fetches the chunks and materialises the completed files (newest manifest per name wins, path-traversal guarded). An encrypted folder is sealed manifests behind a pre-shared-key topic (§7).

Custody and the store. Parts live in the ordinary store, which evicts under pressure; a file still being assembled is pinned — interior manifests included, since losing one would hide its whole subtree. Given a spill directory the store is write-through: every envelope lands on disk as it arrives and memory is a cache in front of it, so a node carries what its disk holds rather than its RAM. A restart resumes, and adoption is safe because an id is the hash of its bytes, so a tampered spill directory cannot inject anything. With no directory, nothing is written and the store behaves as the in-memory map it replaced — the right answer in a browser.

Sessions — a UDP-like link, and a reliable stream on it

A datagram (0x04) is an ordinary unicast envelope whose payload is [0x04][port:2][seq:8][sealed_bytes], signed by the sender and sealed to the peer's prekey. dial(peer, port) returns a session — pure local state, no handshake, because identity is the address. Receive verifies the sender (its key must hash to the session peer), decrypts, and runs a DTLS-style 64-wide replay window. The first datagram floods to discover a route; the signed reply teaches the reverse path (§4), so the rest go directed. Because the address is a key rather than an IP, roaming and NAT rebinding stop being special cases — the link doesn't break when you switch Wi-Fi to cellular, the way Mosh survives roaming.

On top of that, an optional Go-Back-N reliable stream: the sender streams [F_DATA][offset:8][len:2][bytes] within a fixed window and rewinds to the last acked offset on timeout; the receiver accepts only in-order bytes and cumulatively ACKs the next offset it needs. A fixed window and fixed timeout on purpose — it is enough to carry an ordered byte stream, and it is endpoint state only, so it never reintroduces stream semantics into relays.

The honest limit: interactivity tracks the real path RTT. On a LAN or direct radio link it is Mosh-grade; over a multi-hop opportunistic path the datagrams still flow but degrade to store-and-forward. The abstraction is uniform; the experience follows the physics of the link. For a negotiated low-latency pipe that skips the mesh entirely, see Direct.

Request/response — RPC as a convention

A service is a topic or address a node serves. A request (0x02) carries method/path/body, sealed to the service's prekey with a request-id nonce; a response (0x03) goes back along the reverse path the request taught (§4). Large bodies ride the object layer. A service is an ordinary (request) -> response function, so nobody learns a new programming model; to reach the existing web, an HTTP bridge proxies to a local http://… service and back.

A free CDN falls out of it. Responses are content-addressed envelopes every relay stores, so a read-only response marked cacheable can be answered by any node that carried it — the store is the cache, INV/WANT is the cache-fill.

Feeds — pub/sub over topics

A feed is just a topic: publish a tagged event (0x05), subscribers get everything. Retention is whatever the nodes on hand are willing to carry, and a late joiner backfills history from any peer's store via INV/WANT. No special infrastructure — a feed is emergent from topics plus the store-and-sync the router already does. It is the signed-gossip model behind Nostr, minus the JSON, the dedicated relays and the always-on internet.

Groups, invites, and what "revoke" can mean

An encrypted topic (§7.1) is how a private group is built: members seal every message under a shared key, the mesh carries it obliviously, only key-holders read it. invite::encode_group renders one as a single line:

spore-group:<64 hex — the whole 32-byte key>?n=<name>&k=<checksum>

Deliberately not the spore: prefix an address invite uses, because the two are not the same kind of object and must not be interchangeable when pasted. The checksum covers key and name: a mistyped key would otherwise open a room that is cryptographically fine and socially empty, which reads as "a group nobody has posted to yet" rather than as an error.

The invite string is the key. In a group with no roster, holding the key is what being a member means. Two consequences a client must surface rather than bury: anyone who reads it joins (a screenshot works as well as being told, so show it on request rather than beside the conversation), and it cannot be recalled — a copy already taken keeps opening everything sealed under that key.

What is available is moving the group forward, and the three key changes are not interchangeable:

So "revoke" is real but narrower than the word suggests, and the honest phrasing is forward-only. SPORE holds no member list, so who the remaining members are is the application's knowledge and never the protocol's claim: a client must not render a "remove member" control implying the protocol enforced it.

Two things this does not solve, neither of them a cryptography problem. There is no roster and no arbiter of one — a partitioned mesh can leave two halves on different keys, and key_id makes that divergence visible rather than silent, but visible is not solved. And a stolen prekey secret still follows along: healing contributions are sealed to members' prekeys, so someone holding a member's prekey secret opens every contribution addressed to it until that prekey ages out (§7.2).

Appendix — chat attachments

A UX convention that is not obvious from the code, kept so a later change doesn't undo it by accident. An attachment travels as two envelopes: the file's manifest+chunks (the ordinary publish path, sealed to the peer when known), and a normal DATA body whose trailing lines carry one marker per attachment, in send order:

📎 <filename> | spore:<hex-magnet> | <mime>

Matched by (?m)^📎 (.+) \| spore:([0-9a-fA-F]{16,}) \| (\S+)$, applied globally rather than to the first match only. Application-level only: relays and non-SPORE clients see opaque UTF-8, and a client that doesn't parse it shows the marker text — a reasonable fallback. Distinct from the feed's image form ![name](spore:<magnet>), which has nowhere to carry a mime type and stays single-file; chat needs the mime to choose image-preview vs file-chip.

Every file in a batch is size-checked before any is published, so a refusal never leaves orphaned manifests behind. The sender stamps the full attachment list onto its own message (local bytes are cached immediately — our own files never come back through the mesh) and the receiver parses the markers onto the received one, so each attachment is part of one bubble rather than a separate one per file. Only sealed DM attachments get that merged bubble, because only they are guaranteed a marker sender.

Part IV — Host contract

The runtime contract — what the host must supply

The protocol is pure; it holds no OS. A conformant node needs four things from whatever runs it, and gets them wrong silently if it does not ask.

• Randomness. A CSPRNG for the signing seed, prekey secrets, ratchet keys, mix padding and decoys, and CSMA backoff. Prekey secrets MUST be random and MUST NOT be derivable from the identity seed (§7.2).
• Time. Expiry is wall-clock unix seconds. A node with no trusted clock MUST NOT infer age from a clock it does not have: it relays regardless, ages by dwell, and drops after 7 local days (§5.7). Time is supplied per call, never read by the protocol.
• Custody. Received envelopes are held until the room is needed and served on WANT (§6). The bytes may live anywhere — memory, disk, flash, remote store. Custody is untrusted storage: an entry read back MUST be re-verified against its ID before it is served, and a mismatch MUST read as "not held" so the mesh re-fetches. An ID is the hash of its bytes, so this is always checkable.
• Scheduling. Four duties MUST run on a timer, not only on arrival: the sweep, prekey rotation (§7.2), Trickle beacons (§5.4b), and ACKREQ resend backoff (§5.4d). A node driven only by inbound traffic stalls all four — it stops pruning, stops advancing forward secrecy, and never retries. Three are pure and belong to the protocol (here, Node::tick); beaconing is the runtime's own timer, because deciding to emit on an interface lives on the far side of the transport boundary. A runtime that drives only the core's tick never beacons, and is not conformant.

Transport is not a fifth nutrient — it is the boundary the other four are stated across. The protocol names interfaces but never opens one; bytes in and out are the edge. See Part IV for the model and Part II's bindings for the shapes.

Where the core runs

The core is one implementation of the protocol — the same bytes on every machine, carrying nothing about where it landed. Anything that hosts it is a runtime: a language binding, a daemon, a browser worker, a microcontroller firmware. Runtimes vary enormously; what they must provide does not — the four nutrients in the runtime contract above, and nothing else.

The image, once, because it is the whole idea: the core is a spore and a runtime is the soil it lands in. Past this paragraph the docs use the plain words — core, runtime, nutrient — per the legend below.

One noun per concept, because six words for "the thing that hosts the core" is six chances to think they are different things:

Two words are reserved: seed always means the 32-byte signing seed, never the core; spore is the protocol's name.

Runtimes vary; nutrients do not. An ESP32 firmware, a desktop daemon and a browser worker are not three architectures — they are three runtimes filling the same four holes, richly or thinly. Where a runtime cannot supply one it says so rather than pretending: no disk means no spill, and the honest consequence (a smaller store) is surfaced, not hidden. A thin runtime is a profile, not a degraded build.

What keeps the core portable. It must compile for ESP32, Android, Windows, Linux, macOS and the browser — all six built on every PR, from the same crate. Four rules follow, the first three enforced automatically because the wasm and ESP32 jobs stop compiling if they break, and the fourth written down because nothing catches it:

1. No filesystem — reach storage only through the storage nutrient.
2. No threads — wasm32-unknown-unknown has none; the layer is driven by the host's tick, exactly as the core already is.
3. No new dependencies unless they build on Espressif's Xtensa Rust fork.
4. No reading the clock. SystemTime::now() compiles on wasm and then panics at runtime, so no compile guard catches it. Time arrives as a now: u32 parameter; clock reads stay in the native-only layer.

Bridges are open; nutrients are closed. Anyone may add a bridge — it only moves envelope bytes in and out, and every medium is one of the five shapes in Part II's bindings. But nothing may add a fifth nutrient, because that is the contract every runtime has to satisfy. Neighbors<U> is the shared address resolver every bridge uses — SPORE's ARP, where U is whatever the medium calls a peer.

Façades attach to the runtime, not to the core. A communicator — threads, rooms, feed, library, public folder — is one client of the core, never part of it. That is why the chat UI is replaceable and the protocol is not.

One place the metaphor lies, worth saying plainly: soil is passive and a runtime is not. The runtime owns main(), drives the tick, and decides when to flush. It hosts the core; it does not merely surround it.
